"Give your Horse the Ride Of their Life" In a Bockmann PORTAX LK 2023

Portax LK 2023

Taller-Longer-Better Specifically

Designed & Configured For Larger Horses

We really appreciate the extra room having an 18-1 warmblood and a 16-3 ourselves!

GIVE YOUR HORSES THE RIDE OF THEIR LIFE IN A BOCKMANN FROM RIVERSIDE TRAILERS AND HORSEBOXES LTD

Standard Specifications & Dimensions:

Weight: 1200kg

Tow rating: 2700kg

Payload 1500Kg

Interior dimensions: 2350mm high x 1750mm wide x 4175mm long

Exterior dimensions: 2865mm high x 2350mm wide x 5405mm long

Horse bay dimensions: 875mm wide x 1800 mm to 1900 mm long (adjustable)

Features

Fully galvanized steel frame designed for heavy loads (galvanized steel frame with 8-point bolt connection to the longitudinal beam construction)

Total weight 2.7t

Boeckmann class-leading WCF® chassis (independent 4-wheel sprung suspension)

Superb German four-wheel mechanical braking system featuring auto reverse

Aluminium floor covered with anti-slip rubber flooring (fully glued and sealed)

Cast lockable Knott coupling (fits 50mm ball size)

Double web profile anodised aluminium side walls (2100mm high)

Aerodynamic fibreglass bow, roof and fenders in anthracite-metallic

4 large tinted perspex sliding windows

Panoramic front window

Air vent in fibreglass roof

Full height access doors

Rear ramp/door combination

Full height front ramp (ensuring low egress angle)

Ramp with gas shocks and non-slip rubber safety mat with treads and side stops

Boeckmann height & length adjustable, external rapid release safety stall bars (MSS)

Swivelling and fully removable centre partition with central post - 165cm high

Durable High-Density Polyethylene internal side kick protection

Additional wear mat in front leg area for extra durability

Padded sides and chest bars

Full height walk-in airtight and fully sealed tack room with extendable saddle racks, bridle hooks, mirror, shovel & brush, interior lighting - self-draining and well ventilated

Interior lighting

Comprehensive 2 year warranty, 20 year manufactures warranty on floor

Metallic Blue,roof and front bow

Other Optional extras fitted to trailer due in

Alloy wheels

Tie Bars on both sides

12v socket in tack area

Factory fitted extended partition

A little about Bockmann,

The most highly regarded trailer manufacturer in Europe with top riders such as :

Isabell Werth - "The Most Decorated Dressage Rider Of All Time!" using Bockmann Trailers and Horseboxes.

Established in 1956 with a reputation for manufacturing trailers to the highest design and manufacturing standard ensuring the safest possible journey for you and your horses.

At Riverside Trailers And Horseboxes we are often asked why we selected Bockmann as the only trailer manufacturer we will represent.

For us it was that after much research and having owned other makes of trailer we were only prepared to travel our horses in trailers made by Bockmann.

Why?

The suspension which is manufactured to automotive standards provides added safety, stability and comfort .

The floors are made with a closed section aluminum profile where the horse stands ensuring extra strength in this critical area.

Quiet, we were aware of how quiet they are the first time we towed one and having opened the car window did not hear all those loud rattles from the trailer.

Bockmann Portax LK 2023

Nationwide Delivery Available

visit us at

TrailersAndHorseboxes.Com

or in person at

Riverside Trailers And Horseboxes Ltd

TF10 8NJ
